Motocross Bikes
2023KTM 125 SX
34 fields on record
The 2023 KTM 125 SX is a lightweight two-stroke offroad machine designed for young riders and beginners stepping up to competitive motocross. Its nimble 124.8cc engine delivers responsive power with minimal weight, making it ideal for learning proper technique on the track. Known for its sharp handling and KTM's proven reliability, the 125 SX remains the entry-level choice for aspiring motocross racers.
- Capacity
- 124.8 ccm
- Engine
- Single, two-stroke
- Gearbox
- 6-speed
- Dry weight
- 92.4 kg
- Seat height
- 958 mm
- Power
- 15.0 HP (10.9 kW)
What’s new for the 2023 KTM 125 SX
vs the 2022| Spec | 2022 | 2023 |
|---|---|---|
| Dry weight | 87.5 kg (192.9 pounds) | 92.4 kg (203.7 pounds) |
| Fuel capacity | 7.50 litres (1.98 US gallons) | 7.20 litres (1.90 US gallons) |
Other years
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2025
2026
2027
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for closed-course motocross racing, it excels at jumps, berms, and rapid direction changes on dirt tracks rather than any street use.
- Built for
- Light, explosive, and razor-sharp in handling, it rewards aggressive riding with a peaky two-stroke power band and minimal weight to manage.
- Not ideal for
- It is not suitable for commuting, highway travel, passengers, or riders seeking comfort, storage, or a forgiving low-end power delivery.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 124.8 ccm
- Power
- 15.0 HP (10.9 kW)
- Engine type
- Single, two-stroke
- Power/weight ratio
- 0.1623 HP/kg (dry)
- Bore x stroke
- 54.0 x 54.5 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Vitesco Technologies EMS
- Lubrication system
- Wet sump
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet multi-disc DS clutch, Brembo hydraulics
Dimensions & weight
- Wheelbase
- 1489 mm
- Seat height
- 958 mm
- Dry weight
- 92.4 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 359 mm
Chassis & suspension
- Frame
- Central double-cradle-type 25CrMo4 steel
- Front suspension
- WP XACT-USD, Ø 48 mm
- Rear suspension
- WP XACT Monoshock with linkage
- Front wheel travel
- 310 mm
- Rear wheel travel
- 300 mm
- Rake (fork angle)
- 26.1°
- Trail
- 120 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 220 mm
- Front tyre
- 110-17
- Rear tyre
- 150-17
Other
- Color options
- White/orange/grey
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2003 | 2009 | 2015 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc | 125 cc |
| Dry weight | 94 kg | 91 kg | 91 kg | 88 kg | 92 kg | 92 kg |
| Seat height | 925 mm | 985 mm | 992 mm | 950 mm | 958 mm | 958 mm |
| Fuel capacity | 7.5 L | 8 L | 7.5 L | 7.5 L | 7.2 L | 7.2 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 125 SX?
The 2023 KTM 125 SX has a Capacity of 124.8 ccm (7.62 cubic inches).
What engine power does the KTM 125 SX have?
The 2023 KTM 125 SX has a Power of 15.0 HP (10.9 kW).
How many gears does the KTM 125 SX have?
The 2023 KTM 125 SX has a Gearbox of 6-speed.
How much does the KTM 125 SX weigh?
The 2023 KTM 125 SX has a Dry weight of 92.4 kg (203.7 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2023 KTM 125 SX is a powerful and agile motocross bike that is sure to impress both amateur and professional riders. With its lightweight frame and top-of-the-line suspension, this bike offers excellent handling and maneuverability on the track. The 125cc engine provides plenty of power, allowing riders to conquer even the most challenging of courses. Additionally, the bike's sleek and modern design is sure to turn heads both on and off the track. Overall, the 2023 KTM 125 SX is a fantastic choice for anyone looking for a high-performance motocross bike.
In conclusion, the 2023 KTM 125 SX is a top-of-the-line motocross bike that offers exceptional performance and handling. Whether you're a seasoned pro or just starting out in the sport, this bike is sure to impress with its powerful 125cc engine and agile maneuverability on the track. Additionally, the bike's sleek and modern design is sure to make a statement wherever you go. Overall, the 2023 KTM 125 SX is a fantastic choice for anyone looking for a high-performance motocross bike that can handle anything the track throws at it.
