Enduro Bikes
2016SWM RS500R
38 fields on record
The SWM RS 500 R is a lightweight single-cylinder enduro designed for off-road enthusiasts and trail riders seeking an affordable, nimble machine. Its 112 kg dry weight and manageable 963 mm seat height make it accessible to riders of varying experience levels. Known for reliability and simplicity, this liquid-cooled four-stroke excels in technical terrain and recreational riding.
- Capacity
- 500.8 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 112.0 kg
- Seat height
- 963 mm
- Power
- 55.1 HP (40.5 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- This is a dedicated enduro machine built for trail riding, technical off-road terrain, and playful single-track work rather than pavement cruising.
- Built for
- It suits riders who enjoy raw, minimalist off-road machines that prioritize agility and terrain feedback over outright power or creature comforts.
- Not ideal for
- It is not a good fit for riders seeking highway comfort, long-distance touring capability, or a passenger-friendly two-up ride.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 500.8 ccm
- Power
- 55.1 HP (40.5 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4920 HP/kg (dry)
- Bore x stroke
- 97.0 x 67.8 mm
- Compression
- 12.9:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Electronic
- Lubrication system
- Dry sump with two oil pump rotor and cartridge filter
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiplate type; mecanical control
Dimensions & weight
- Wheelbase
- 1495 mm
- Overall length
- 2240 mm
- Overall width
- 820 mm
- Overall height
- 1285 mm
- Seat height
- 963 mm
- Dry weight
- 112.0 kg
- Fuel capacity
- 7.20 litres
- Ground clearance
- 300 mm
Chassis & suspension
- Frame
- Single beam double cradle main frame
- Front suspension
- Kayba Upside-Down fork
- Rear suspension
- Kayba ´Soft Damp´monoshock absorber with adjustment
- Front wheel travel
- 295 mm
- Rear wheel travel
- 296 mm
- Trail
- 106 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc
- Rear brakes diameter
- 240 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Red/white/yellow/black
- Comments
- SWM is short for Speedy Working Motors in Italy. Cooperated with Chinese Shineray.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2016 | 2018 | 2019 | 2023 | 2024 |
|---|---|---|---|---|---|
| Capacity | 501 cc | 501 cc | 501 cc | 501 cc | 501 cc |
| Dry weight | 112 kg | 112 kg | 112 kg | 116 kg | 116 kg |
| Seat height | 963 mm | 963 mm | 963 mm | 955 mm | 955 mm |
| Fuel capacity | 7.2 L | 7.2 L | 7.2 L | 7.5 L | 7.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the SWM RS500R?
The 2016 SWM RS500R has a Capacity of 500.8 ccm (30.56 cubic inches).
What engine power does the SWM RS500R have?
The 2016 SWM RS500R has a Power of 55.1 HP (40.5 kW).
How many gears does the SWM RS500R have?
The 2016 SWM RS500R has a Gearbox of 6-speed.
How much does the SWM RS500R weigh?
The 2016 SWM RS500R has a Dry weight of 112.0 kg (246.9 pounds).
