Enduro Bikes
2023SWM RS500R
39 fields on record
The 2023 SWM RS500R is a lightweight enduro motorcycle ideal for trail riders and off-road enthusiasts seeking affordable adventure. Powered by a 501cc liquid-cooled single-cylinder four-stroke engine producing 34 horsepower, it delivers nimble handling and approachable performance. Known for its simplicity and value proposition, the RS500R excels in off-road exploration and technical terrain riding.
- Capacity
- 501.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 116.0 kg
- Seat height
- 955 mm
- Power
- 33.5 HP (24.5 kW)
What’s new for the 2023 SWM RS500R
vs the 2020| Spec | 2020 | 2023 |
|---|---|---|
| Power | 26.8 HP (20.0 kW) @ 7500 RPM | 33.5 HP (24.5 kW) |
| Front suspension | Upside down hydraulic fork | KAYABA. Upside down telescopic hydraulic fork with advanced axle, compression and rebound dumping adjustment |
| Rear suspension | Progressive link system with single adjustable shock absorber | KAYABA. Progressive “soft damp” single hydraulic shock absorber, spring preload, compression and rebound adjustements |
| Front brakes | Single disc. Brembo | Single disc. Brembo, hydraulic control and floating caliper |
| Rear brakes | Single disc. Brembo | Single disc. Brembo, hydraulic control and floating caliper |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily for off-road trail riding, with enough road manners to link trails where it is road-legal.
- Built for
- An enduro bike from SWM with a 501cc engine; its character is versatile and engaging, with 34 hp on tap.
- Not ideal for
- Not for long road journeys, passengers or motorway riding.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 501.0 ccm
- Power
- 33.5 HP (24.5 kW)
- CO2 Emissions
- 4 CO2 g/km
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.2888 HP/kg (dry)
- Bore x stroke
- 97.0 x 67.5 mm
- Compression
- 12.9:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Electronic
- Lubrication system
- Wet sump
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Wet, multiplate
Dimensions & weight
- Wheelbase
- 1485 mm
- Overall length
- 2240 mm
- Overall width
- 820 mm
- Overall height
- 1285 mm
- Seat height
- 955 mm
- Dry weight
- 116.0 kg
- Fuel capacity
- 7.50 litres
- Ground clearance
- 300 mm
Chassis & suspension
- Frame
- High strength steel tubular
- Front suspension
- KAYABA. Upside down telescopic hydraulic fork with advanced axle, compression and rebound dumping adjustment
- Rear suspension
- KAYABA. Progressive “soft damp” single hydraulic shock absorber, spring preload, compression and rebound adjustements
- Front wheel travel
- 295 mm
- Rear wheel travel
- 296 mm
- Trail
- 106 mm
Brakes & wheels
- Front brakes
- Single disc. Brembo, hydraulic control and floating caliper
- Front brakes diameter
- 260 mm
- Rear brakes
- Single disc. Brembo, hydraulic control and floating caliper
- Rear brakes diameter
- 240 mm
- Front tyre
- 90/90-21
- Rear tyre
- 140/80-18
Other
- Color options
- Red/Black
- Comments
- Italian brand.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2016 | 2018 | 2019 | 2023 | 2024 |
|---|---|---|---|---|---|
| Capacity | 501 cc | 501 cc | 501 cc | 501 cc | 501 cc |
| Dry weight | 112 kg | 112 kg | 112 kg | 116 kg | 116 kg |
| Seat height | 963 mm | 963 mm | 963 mm | 955 mm | 955 mm |
| Fuel capacity | 7.2 L | 7.2 L | 7.2 L | 7.5 L | 7.5 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the SWM RS500R?
The 2023 SWM RS500R has a Capacity of 501.0 ccm (30.57 cubic inches).
What engine power does the SWM RS500R have?
The 2023 SWM RS500R has a Power of 33.5 HP (24.5 kW).
How many gears does the SWM RS500R have?
The 2023 SWM RS500R has a Gearbox of 6-speed.
How much does the SWM RS500R weigh?
The 2023 SWM RS500R has a Dry weight of 116.0 kg (255.7 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2023 SWM RS500R is an impressive off-road motorcycle that offers a powerful and reliable performance. Its 501cc engine delivers plenty of torque and horsepower, making it capable of tackling even the most challenging terrain. The bike's suspension system is also top-notch, providing excellent handling and control over rough and uneven surfaces. With its aggressive styling and durable construction, the RS500R is sure to be a popular choice for riders looking for a capable and versatile off-road machine.
Overall, the 2023 SWM RS500R is a solid choice for anyone in the market for a high-performance off-road motorcycle. Its powerful engine, excellent suspension, and rugged build quality make it well-suited for tackling any off-road adventure. Whether you're hitting the trails or competing in off-road races, the RS500R has the performance and durability to keep you riding with confidence.
