2014KTM 1290 Super Duke R
43 fields on record
The 2014 KTM 1290 Super Duke R is a hooligan's naked bike, built for experienced riders who want maximum attitude on road and track day alike. Its 1301 cc V-twin punches out 170.3 hp through a tubular space frame with WP suspension at both ends. Nicknamed "The Beast," it is best known for brutal midrange torque and effortless wheelies.
- Capacity
- 1301.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 189.0 kg
- Seat height
- 835 mm
- Power
- 170.3 HP (127.0 kW) @ 8865 RPM
What’s new for the 2014 KTM 1290 Super Duke R
vs the 2013| Spec | 2013 | 2014 |
|---|---|---|
| Power | 160.0 HP (117.7 kW) | 170.3 HP (127.0 kW) @ 8865 RPM |
| Front brakes | Double disc | Double disc. Radially mounted four-piston brake calipers |
| Rear brakes | Single disc | Single disc. Two-piston brake caliper; fixed brake disc |
| Wheelbase | 1450 mm (57.1 inches) | 1482 mm (58.3 inches) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for technical off-road riding, tight trails, and competitive enduro use rather than any road-going performance.
- Built for
- A raw, high-revving two-stroke enduro weapon that rewards aggressive throttle control and precise body positioning over raw straight-line speed.
- Not ideal for
- Not suitable for riders wanting a comfortable road bike, highway touring, or passenger carrying capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 1301.0 ccm
- Power
- 170.3 HP (127.0 kW) @ 8865 RPM
- CO2 Emissions
- 154 CO2 g/km
- EPA Certificate No.
- EKTXC1.20ADV-005-R01
- EPA Est. Fuel Consumption
- 6.55 L/100km (35.9 US mpg)
- EPA CO Emissions
- 4.1 CO g/km
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.9011 HP/kg (dry)
- Bore x stroke
- 108.0 x 71.0 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Ride-by-wire
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Forced oil lubrication with 3 rotor pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- PASC™ anti-hopping clutch/ hydraulically operated
Performance
- 0-60 mph
- 2.60 seconds
- 0-100 km/h (0-62 mph)
- 3.20 seconds
Dimensions & weight
- Wheelbase
- 1482 mm
- Seat height
- 835 mm
- Dry weight
- 189.0 kg
- Fuel capacity
- 18.00 litres
- Ground clearance
- 140 mm
Chassis & suspension
- Frame
- Tubular space frame
- Front suspension
- WP Suspension Up Side Down
- Rear suspension
- WP Suspension Monoshock
- Front wheel travel
- 125 mm
- Rear wheel travel
- 156 mm
- Rake (fork angle)
- 25.2°
Brakes & wheels
- Front brakes
- Double disc. Radially mounted four-piston brake calipers
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. Two-piston brake caliper; fixed brake disc
- Rear brakes diameter
- 240 mm
- ABS
- Optional
- Front tyre
- 120/70-17
- Rear tyre
- 200/55-17
Other
- Color options
- Orange, black
- Fuel Tank Material
- Plastic
Specs last verified against published sources: .
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2014 | 2016 | 2019 | 2021 | 2024 |
|---|---|---|---|---|---|---|
| Capacity | 1299 cc | 1301 cc | 1301 cc | 1301 cc | 1301 cc | 1301 cc |
| Dry weight | 189 kg | 189 kg | 192 kg | 195 kg | 189 kg | 209 kg |
| Seat height | 835 mm | 835 mm | 835 mm | 835 mm | 835 mm | 835 mm |
| Fuel capacity | 18 L | 18 L | 18 L | 18 L | 16 L | — |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Safety Recalls
⚠ 1 recall may applyFUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLYJul 2015 · 15V441000
KTM North America, Inc. (KTM) is recalling all model year 2014 1290 Super Duke R motorcycles manufactured July 1, 2013, to April 30, 2014. The affected motorcycles may leak fuel from the threaded inserts at the rear of the gas tank.
Risk: A fuel leak from the threaded inserts, in the presence of an ignition source, may increase the risk of a fire.
Remedy: KTM will notify owners, and dealers will seal the threaded inserts to prevent future fuel leaks. If the motorcycle shows evidence of an existing fuel leak at the threaded insert, the gas tank will be replaced. These repairs will be performed free of charge. The recall began on August 11, 2015. Owners may contact KTM customer service at 1-888-985-6090. KTM's number for this recall is TB1507.
These recalls cover some 2014 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
Source: NHTSA. View all KTM recalls →
Rider Reviews
Common questions
What is the engine size of the KTM 1290 Super Duke R?
The 2014 KTM 1290 Super Duke R has a Capacity of 1301.0 ccm (79.39 cubic inches).
What engine power does the KTM 1290 Super Duke R have?
The 2014 KTM 1290 Super Duke R has a Power of 170.3 HP (127.0 kW) @ 8865 RPM.
How many gears does the KTM 1290 Super Duke R have?
The 2014 KTM 1290 Super Duke R has a Gearbox of 6-speed.
How much does the KTM 1290 Super Duke R weigh?
The 2014 KTM 1290 Super Duke R has a Dry weight of 189.0 kg (416.7 pounds).
