Naked Motorcycles
2020KTM 1290 Super Duke R
43 fields on record
The 2020 KTM 1290 Super Duke R is an aggressive naked bike engineered for experienced riders seeking extreme performance and agility. Known for its sharp handling, potent engine delivery, and cutting-edge electronics, it dominates track days and demanding road conditions. Its lightweight chassis and high power-to-weight ratio deliver thrilling acceleration and precise cornering dynamics.
- Capacity
- 1301.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 189.0 kg
- Seat height
- 835 mm
- Power
- 177.0 HP (132.0 kW) @ 9500 RPM
What’s new for the 2020 KTM 1290 Super Duke R
vs the 2019| Spec | 2019 | 2020 |
|---|---|---|
| Power | 174.3 HP (130.0 kW) @ 9750 RPM | 177.0 HP (132.0 kW) @ 9500 RPM |
| Torque | 141.0 Nm (14.4 kgf-m or 104.0 ft.lbs) @ 7000 RPM | 140.0 Nm (14.3 kgf-m or 103.3 ft.lbs) |
| Dry weight | 195.0 kg (429.9 pounds) | 189.0 kg (416.7 pounds) |
| Fuel capacity | 18.00 litres (4.76 US gallons) | 16.00 litres (4.23 US gallons) |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built purely for technical off-road riding, tight trails, and competitive enduro use rather than any road-going performance.
- Built for
- A raw, high-revving two-stroke enduro weapon that rewards aggressive throttle control and precise body positioning over raw straight-line speed.
- Not ideal for
- Not suitable for riders wanting a comfortable road bike, highway touring, or passenger carrying capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usRange and running costs
Worked out in your browser - nothing is sent to usBased on the published US (EPA-style) fuel economy estimate and tank size. Real-world figures depend on how and where you ride, and the last litres of a tank are reserve. Prices shown greyed are examples - type your own.
Engine
- Capacity
- 1301.0 ccm
- Power
- 177.0 HP (132.0 kW) @ 9500 RPM
- CO2 Emissions
- 169 CO2 g/km
- EPA Certificate No.
- LKTXC1.30SD5-011
- EPA Est. Fuel Consumption
- 7.22 L/100km (32.6 US mpg)
- EPA CO Emissions
- 0.8 CO g/km
- Torque
- 140.0 Nm (14.3 kgf-m)
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.9365 HP/kg (dry)
- Bore x stroke
- 108.0 x 71.0 mm
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Keihin EMS with RBW, twin ignition
- Aspiration
- Naturally aspirated
- Valves per cylinder
- 4
- Lubrication system
- Forced oil lubrication with 3 pumps
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- PASC slipper clutch, hydraulically actuated
Performance
- 0-60 mph
- 3.10 seconds
- 0-100 km/h (0-62 mph)
- 3.20 seconds
Dimensions & weight
- Wheelbase
- 1482 mm
- Seat height
- 835 mm
- Dry weight
- 189.0 kg
- Fuel capacity
- 16.00 litres
- Ground clearance
- 160 mm
Chassis & suspension
- Frame
- Chrome-moly tubular space frame, powder-coated
- Front suspension
- WP USD Ø 48 mm
- Rear suspension
- WP Monoshock
- Front wheel travel
- 125 mm
- Rear wheel travel
- 140 mm
- Rake (fork angle)
- 25.2°
Brakes & wheels
- Front brakes
- Double disc. ABS. Radially mounted four-piston brake calipers
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. ABS. Two-piston brake caliper. fixed brake disc
- Rear brakes diameter
- 240 mm
- ABS
- Yes
- Front tyre
- 120/70-17
- Rear tyre
- 200/55-17
Other
- Color options
- Black/orange, orange/blue
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2013 | 2016 | 2019 | 2020 | 2021 | 2024 |
|---|---|---|---|---|---|---|
| Capacity | 1299 cc | 1301 cc | 1301 cc | 1301 cc | 1301 cc | 1301 cc |
| Dry weight | 189 kg | 192 kg | 195 kg | 189 kg | 189 kg | 209 kg |
| Seat height | 835 mm | 835 mm | 835 mm | 835 mm | 835 mm | 835 mm |
| Fuel capacity | 18 L | 18 L | 18 L | 16 L | 16 L | — |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Safety Recalls
⚠ 2 recalls may applyELECTRICAL SYSTEM:WIRINGDec 2022 · 22V900000
KTM North America, Inc. (KTM) is recalling all 2020-2022 1290 Super Duke R and Super Duke R EVO motorcycles. The main wiring harness may be misrouted or missing parts, which can cause wiring harness damage and result in an electrical short-circuit or engine stall.
Risk: An engine stall can increase the risk of a crash.
Remedy: Dealers will inspect and repair the main wiring harness installation, as necessary, free of charge. Owner notification letters were mailed January 26, 2023. Owners may contact KTM customer service at 1-888-985-6090. KTM's number for this recall is KTB2211.
ELECTRICAL SYSTEM:WIRINGFeb 2021 · 21V122000
KTM North America, Inc. (KTM) is recalling certain 2020 1290 Super Duke R motorcycles. The wiring harness located in the rear of the motorcycle may be routed incorrectly, which could result in wiring damage and an electrical short-circuit.
Risk: An electrical short-circuit could cause the engine to stall, increasing the risk of a crash or injury.
Remedy: KTM will notify owners, and dealers will inspect the rear wiring harness, and repair as necessary. In addition, dealers will modify a piece of the bodywork called the "tail end lower part" to correct the routing of the wiring harness and add wiring protection and cable ties. Repairs will be performed free of charge. The recall began March 24, 2021. KTM's number for this recall is TB2104.
These recalls cover some 2020 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
Source: NHTSA. View all KTM recalls →
Rider Reviews
Common questions
What is the engine size of the KTM 1290 Super Duke R?
The 2020 KTM 1290 Super Duke R has a Capacity of 1301.0 ccm (79.39 cubic inches).
What engine power does the KTM 1290 Super Duke R have?
The 2020 KTM 1290 Super Duke R has a Power of 177.0 HP (132.0 kW) @ 9500 RPM.
How many gears does the KTM 1290 Super Duke R have?
The 2020 KTM 1290 Super Duke R has a Gearbox of 6-speed.
What is the torque of the KTM 1290 Super Duke R?
The 2020 KTM 1290 Super Duke R has a Torque of 140.0 Nm (14.3 kgf-m or 103.3 ft.lbs).
How much does the KTM 1290 Super Duke R weigh?
The 2020 KTM 1290 Super Duke R has a Dry weight of 189.0 kg (416.7 pounds).
