2008Yamaha TT-R230

★ 3.0

40 fields on record

The 2008 Yamaha TT-R230 is a lightweight enduro bike ideal for novice and intermediate off-road riders. Its air-cooled single-cylinder engine delivers accessible power for trail riding and general dirt work. Known for reliability and easy handling, it excels as an affordable entry-level machine for learning dirt bike fundamentals.

Capacity: 223.0 ccm
Engine: Single, four-stroke
Gearbox: 6-speed
Dry weight: 107.0 kg
Seat height: 869 mm
Power: 19.6 HP (14.4 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2008 Yamaha TT-R230

vs the 2007

Spec	2007	2008
Dry weight	109.8 kg (242.1 pounds)	107.0 kg (235.9 pounds)
Front suspension	36mm telescopic fork	Telescopic fork
Rear suspension	Link-type single shock	Single shock

Other years 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail82%

Cornering55%

City riding30%

Daily riding30%

Touring20%

Two-up10%

Track10%

Best for: Built primarily as a trail and recreational dual-purpose off-road bike rather than a performance or commuting machine.
Built for: A friendly, forgiving, low-stress trail bike with smooth, predictable power and nimble, flickable handling on tight or technical terrain.
Not ideal for: Not a good fit for riders wanting highway speed, long-distance touring comfort, or two-up passenger capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 869mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with tip-toe one foot on the 2008 Yamaha TT-R230, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 223.0 ccm
Power: 19.6 HP (14.4 kW)
Engine type: Single, four-stroke
Power/weight ratio: 0.1832 HP/kg (dry)
Bore x stroke: 70.0 x 58.0 mm
Compression: 9.5:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric
Ignition: CDI
Valves per cylinder: 2
Lubrication system: Wet, multidisc
Torque: Not on record - add it

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: Multiplate wet clutch

Dimensions & weight

Wheelbase: 1384 mm
Overall length: 2065 mm
Overall width: 800 mm
Overall height: 1181 mm
Seat height: 869 mm
Dry weight: 107.0 kg
Wet weight: 116.1 kg
Fuel capacity: 7.90 litres
Ground clearance: 295 mm

Chassis & suspension

Frame: Steel
Front suspension: Telescopic fork
Rear suspension: Single shock
Front wheel travel: 241 mm
Rear wheel travel: 221 mm
Rake (fork angle): 26.0°
Trail: 112 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 194 mm
Rear brakes: Expanding brake (drum brake)
Rear brakes diameter: 130 mm
Front tyre: 80/80-21
Rear tyre: 100/80-18

Other

Color options: Blue/white

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2007	2008	2012	2017	2022	2027
Capacity	223 cc	223 cc	223 cc	223 cc	223 cc	223 cc
Dry weight	110 kg	107 kg	107 kg	107 kg	107 kg	107 kg
Seat height	871 mm	869 mm	869 mm	871 mm	871 mm	871 mm
Fuel capacity	7.9 L	7.9 L	8 L	8 L	8 L	8 L
