Enduro Bikes
2017Yamaha TT-R230
41 fields on record
The 2017 Yamaha TT-R230 is a versatile dual-sport designed for beginner to intermediate riders seeking an affordable, reliable bike for both trail and light street use. Known for its manageable 871mm seat height, lightweight construction at 114kg, and excellent fuel efficiency, it excels at introducing new riders to off-road riding. Its adjustable monocross rear suspension and capable ground clearance make it equally at home navigating tight trails or cruising country roads.
- Capacity
- 223.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 107.0 kg
- Seat height
- 871 mm
- Power
- 19.6 HP (14.4 kW)
Other years
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2024
2025
2026
2027
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a trail and recreational dual-purpose off-road bike rather than a performance or commuting machine.
- Built for
- A friendly, forgiving, low-stress trail bike with smooth, predictable power and nimble, flickable handling on tight or technical terrain.
- Not ideal for
- Not a good fit for riders wanting highway speed, long-distance touring comfort, or two-up passenger capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 223.0 ccm
- Power
- 19.6 HP (14.4 kW)
- Torque
- 18.6 Nm (1.9 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1832 HP/kg (dry)
- Bore x stroke
- 70.0 x 58.0 mm
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 2
- Lubrication system
- Wet, multidisc
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiplate wet clutch
Dimensions & weight
- Wheelbase
- 1384 mm
- Overall length
- 2065 mm
- Overall width
- 800 mm
- Overall height
- 1181 mm
- Seat height
- 871 mm
- Dry weight
- 107.0 kg
- Wet weight
- 114.0 kg
- Fuel capacity
- 8.00 litres
- Ground clearance
- 295 mm
Chassis & suspension
- Frame
- Steel, diamond
- Front suspension
- Telescopic fork
- Rear suspension
- Adjustable link-type Monocross
- Front wheel travel
- 240 mm
- Rear wheel travel
- 221 mm
- Rake (fork angle)
- 26.5°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 220 mm
- Rear brakes
- Expanding brake (drum brake)
- Rear brakes diameter
- 130 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/100-18
Other
- Color options
- Blue/White
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2007 | 2012 | 2017 | 2022 | 2027 |
|---|---|---|---|---|---|
| Capacity | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc |
| Dry weight | 110 kg | 107 kg | 107 kg | 107 kg | 107 kg |
| Seat height | 871 mm | 869 mm | 871 mm | 871 mm | 871 mm |
| Fuel capacity | 7.9 L | 8 L | 8 L | 8 L | 8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha TT-R230?
The 2017 Yamaha TT-R230 has a Capacity of 223.0 ccm (13.61 cubic inches).
What engine power does the Yamaha TT-R230 have?
The 2017 Yamaha TT-R230 has a Power of 19.6 HP (14.4 kW).
How many gears does the Yamaha TT-R230 have?
The 2017 Yamaha TT-R230 has a Gearbox of 6-speed.
What is the torque of the Yamaha TT-R230?
The 2017 Yamaha TT-R230 has a Torque of 18.6 Nm (1.9 kgf-m or 13.7 ft.lbs) @ 6000 RPM.
How much does the Yamaha TT-R230 weigh?
The 2017 Yamaha TT-R230 has a Dry weight of 107.0 kg (235.9 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2017 Yamaha TT-R230 is a durable and dependable off-road motorcycle that is perfect for both beginners and experienced riders. Its 223cc air-cooled, SOHC four-stroke engine provides plenty of power for tackling a variety of terrains, while its electric start and front disc brake add convenience and safety. With a 6-speed transmission and adjustable suspension, this bike offers a smooth and controlled ride on trails and dirt roads. The comfortable seat and ergonomically designed controls make it easy to handle, and the durable steel frame ensures long-lasting performance. Overall, the 2017 Yamaha TT-R230 is a reliable and versatile choice for anyone looking for a quality off-road motorcycle.
If you're in the market for a capable off-road motorcycle, the 2017 Yamaha TT-R230 is a top choice. With its powerful engine, smooth transmission, and adjustable suspension, this bike offers a comfortable and controlled ride on all types of terrain. The electric start and front disc brake add convenience and safety, while the durable steel frame ensures long-lasting performance. Whether you're a beginner or a seasoned rider, the TT-R230 is a dependable and versatile option for off-road adventures.
