Enduro Bikes
2022Yamaha TT-R230
41 fields on record
The 2022 Yamaha TT-R230 is a lightweight enduro bike designed for beginners and recreational off-road riders seeking an affordable, manageable platform. Its 223cc air-cooled four-stroke engine delivers predictable power delivery and easy handling, making it ideal for trail riding and learning fundamental dirt bike skills. Known for reliability and low maintenance, the TT-R230 excels as an entry-level machine for riders transitioning from smaller bikes or exploring off-road riding.
- Capacity
- 223.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 107.0 kg
- Seat height
- 871 mm
- Power
- 19.6 HP (14.4 kW)
Other years
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
2019
2020
2021
2022
2023
2024
2025
2026
2027
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built primarily as a trail and recreational dual-purpose off-road bike rather than a performance or commuting machine.
- Built for
- A friendly, forgiving, low-stress trail bike with smooth, predictable power and nimble, flickable handling on tight or technical terrain.
- Not ideal for
- Not a good fit for riders wanting highway speed, long-distance touring comfort, or two-up passenger capability.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 223.0 ccm
- Power
- 19.6 HP (14.4 kW)
- Torque
- 18.6 Nm (1.9 kgf-m) @ 6000 RPM
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.1832 HP/kg (dry)
- Bore x stroke
- 70.0 x 58.0 mm
- Compression
- 9.5:1
- Cooling system
- Air
- Fuel system
- Carburettor
- Starting
- Electric
- Ignition
- CDI
- Valves per cylinder
- 2
- Lubrication system
- Wet, multidisc
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- Multiplate wet clutch
Dimensions & weight
- Wheelbase
- 1384 mm
- Overall length
- 2065 mm
- Overall width
- 800 mm
- Overall height
- 1181 mm
- Seat height
- 871 mm
- Dry weight
- 107.0 kg
- Wet weight
- 113.9 kg
- Fuel capacity
- 8.00 litres
- Ground clearance
- 295 mm
Chassis & suspension
- Frame
- Steel, diamond. Aluminum box-section swingarm.
- Front suspension
- Telescopic fork
- Rear suspension
- Adjustable link-type Monocross
- Front wheel travel
- 240 mm
- Rear wheel travel
- 221 mm
- Rake (fork angle)
- 27.0°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc
- Front brakes diameter
- 220 mm
- Rear brakes
- Expanding brake (drum brake)
- Rear brakes diameter
- 130 mm
- Front tyre
- 80/100-21
- Rear tyre
- 100/100-18
Other
- Color options
- Team Yamaha Blue
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2007 | 2012 | 2017 | 2022 | 2027 |
|---|---|---|---|---|---|
| Capacity | 223 cc | 223 cc | 223 cc | 223 cc | 223 cc |
| Dry weight | 110 kg | 107 kg | 107 kg | 107 kg | 107 kg |
| Seat height | 871 mm | 869 mm | 871 mm | 871 mm | 871 mm |
| Fuel capacity | 7.9 L | 8 L | 8 L | 8 L | 8 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Yamaha TT-R230?
The 2022 Yamaha TT-R230 has a Capacity of 223.0 ccm (13.61 cubic inches).
What engine power does the Yamaha TT-R230 have?
The 2022 Yamaha TT-R230 has a Power of 19.6 HP (14.4 kW).
How many gears does the Yamaha TT-R230 have?
The 2022 Yamaha TT-R230 has a Gearbox of 6-speed.
What is the torque of the Yamaha TT-R230?
The 2022 Yamaha TT-R230 has a Torque of 18.6 Nm (1.9 kgf-m or 13.7 ft.lbs) @ 6000 RPM.
How much does the Yamaha TT-R230 weigh?
The 2022 Yamaha TT-R230 has a Dry weight of 107.0 kg (235.9 pounds).
Shop this bike
Affiliate linksWe may earn a commission from qualifying eBay or Amazon purchases made through these links. As an Amazon Associate I earn from qualifying purchases.
The 2022 Yamaha TT-R230 is a top-of-the-line off-road motorcycle that is perfect for riders of all skill levels. With its 223cc air-cooled, SOHC four-stroke engine, this bike delivers smooth and reliable power, making it great for beginners and experienced riders alike. The electric start and low seat height add to its accessibility, while the adjustable suspension and 6-speed transmission provide a versatile and enjoyable riding experience. Whether you're hitting the trails or cruising through the desert, the TT-R230 offers responsive handling and excellent performance.
Overall, the 2022 Yamaha TT-R230 is a fantastic choice for anyone in the market for a reliable and fun off-road motorcycle. The build quality and attention to detail from Yamaha make it a stand-out option in its class. With its combination of power, comfort, and maneuverability, the TT-R230 is a versatile and capable machine that will provide hours of enjoyment on any terrain. If you're looking for a durable and versatile off-road motorcycle, the 2022 Yamaha TT-R230 is definitely worth considering.
