2012KTM 690 SMC R

Rate this bike

37 fields on record

The 2012 KTM 690 SMC R is a lightweight super motard designed for agile, playful riding on both street and light dirt surfaces. Its punchy 690cc single-cylinder engine delivers 66 horsepower with strong mid-range torque, making it ideal for experienced riders seeking nimble handling and urban versatility. Known for its compact frame, responsive performance, and aggressive styling, it excels at quick acceleration and tight cornering.

Capacity: 690.0 ccm
Engine: Single, four-stroke
Gearbox: 6-speed
Dry weight: 142.0 kg
Seat height: 890 mm
Power: 66.0 HP (48.5 kW)

⇄ Compare with another bike ＋ Add to garage All model years

Other years 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail78%

Cornering95%

City riding70%

Daily riding45%

Touring25%

Two-up15%

Track75%

Best for: Built for aggressive cornering, supermoto-style street attack, and tight technical riding rather than long-distance travel.
Built for: A raw, punchy big-bore single with sharp handling, strong midrange torque, and an aggressive, minimalist supermoto personality.
Not ideal for: Not a good fit for riders seeking plush comfort, pillion capability, or relaxed long-haul touring.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 890mm, a rider of 68.9" with a 31" (estimated) inseam will not reach the ground comfortably on the 2012 KTM 690 SMC R, with a relaxed knee angle of around 145 degrees and a forward-leaning riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 690.0 ccm
Power: 66.0 HP (48.5 kW)
Torque: 64.0 Nm (6.5 kgf-m) @ 6000 RPM
Engine type: Single, four-stroke
Power/weight ratio: 0.4648 HP/kg (dry)
Bore x stroke: 102.0 x 84.5 mm
Compression: 12.7:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Ignition: Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Lubrication system: Semi-dry-sump lubrication with 2 rotor pumps

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Chain
Clutch: APTC Anti-hopping clutch / hydraulically operated

Dimensions & weight

Wheelbase: 1480 mm
Seat height: 890 mm
Dry weight: 142.0 kg
Wet weight: 153.5 kg
Fuel capacity: 12.00 litres
Ground clearance: 270 mm

Chassis & suspension

Frame: Tubular space frame made from chrome molybdenum steel, powder-coated
Front suspension: WP Suspension Up Side Down 4860 ROMA
Rear suspension: WP Suspension 4618 with Pro and #8209;Lever linkage
Front wheel travel: 250 mm
Rear wheel travel: 250 mm
Rake (fork angle): 27.0°
Trail: 112 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 320 mm
Rear brakes: Single disc
Rear brakes diameter: 240 mm
Front tyre: 120/70-17
Rear tyre: 160/60-ZR17

Other

Color options: Black/orange/white

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2012	2016	2020	2023	2027
Capacity	690 cc	690 cc	693 cc	693 cc	693 cc
Dry weight	142 kg	141 kg	147 kg	147 kg	152 kg
Seat height	890 mm	890 mm	890 mm	892 mm	899 mm
Fuel capacity	12 L	12 L	13.5 L	13.5 L	13.3 L
