Supermotos
2018KTM 690 SMC R
38 fields on record
The 2018 KTM 690 SMC R is a lightweight supermoto designed for riders seeking aggressive street performance and nimble handling. Known for its agile chassis, responsive ride-by-wire engine, and playful character, it excels in urban environments and tight technical riding. Its compact dimensions and low seat height make it accessible to a wide range of riders.
- Capacity
- 690.0 ccm
- Engine
- Single, four-stroke
- Gearbox
- 6-speed
- Dry weight
- 141.0 kg
- Seat height
- 890 mm
- Power
- 67.0 HP (48.9 kW)
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for aggressive cornering, supermoto-style street attack, and tight technical riding rather than long-distance travel.
- Built for
- A raw, punchy big-bore single with sharp handling, strong midrange torque, and an aggressive, minimalist supermoto personality.
- Not ideal for
- Not a good fit for riders seeking plush comfort, pillion capability, or relaxed long-haul touring.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 690.0 ccm
- Power
- 67.0 HP (48.9 kW)
- Engine type
- Single, four-stroke
- Power/weight ratio
- 0.4752 HP/kg (dry)
- Bore x stroke
- 102.0 x 84.5 mm
- Compression
- 12.7:1
- Cooling system
- Liquid
- Fuel system
- Injection
- Starting
- Electric
- Ignition
- Keihin EMS with RBW, twin ignition
- Lubrication system
- Forced oil lubrication with 2 oil pumps
- Torque
- Not on record - add it
Transmission
- Gearbox
- 6-speed
- Transmission type
- Manual
- Final drive
- Chain
- Clutch
- APTC slipper clutch, hydraulically actuated
Dimensions & weight
- Wheelbase
- 1480 mm
- Seat height
- 890 mm
- Dry weight
- 141.0 kg
- Wet weight
- 153.5 kg
- Fuel capacity
- 12.00 litres
- Ground clearance
- 270 mm
Chassis & suspension
- Frame
- Chromium-Molybdenum steel trellis frame, powder coated
- Front suspension
- WP USD Ø 48 mm
- Rear suspension
- WP shock absorber with Pro-Lever linkage
- Front wheel travel
- 215 mm
- Rear wheel travel
- 250 mm
- Rake (fork angle)
- 27.0°
- Trail
- 112 mm
Brakes & wheels
- Front brakes
- Single disc. Bosch 9M+ ABS. Floating disc. Four-piston calipers. Radially mounted.
- Front brakes diameter
- 320 mm
- Rear brakes
- Single disc. Bosch 9M+ ABS. Floating disc. Single-piston caliper.
- Rear brakes diameter
- 240 mm
- ABS
- Yes
- Front tyre
- 120/70-17
- Rear tyre
- 160/60-ZR17
Other
- Color options
- Black/orange/white
- Comments
- Ride-by-wire system.
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 2012 | 2016 | 2018 | 2020 | 2023 | 2027 |
|---|---|---|---|---|---|---|
| Capacity | 690 cc | 690 cc | 690 cc | 693 cc | 693 cc | 693 cc |
| Dry weight | 142 kg | 141 kg | 141 kg | 147 kg | 147 kg | 152 kg |
| Seat height | 890 mm | 890 mm | 890 mm | 890 mm | 892 mm | 899 mm |
| Fuel capacity | 12 L | 12 L | 12 L | 13.5 L | 13.5 L | 13.3 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the KTM 690 SMC R?
The 2018 KTM 690 SMC R has a Capacity of 690.0 ccm (42.11 cubic inches).
What engine power does the KTM 690 SMC R have?
The 2018 KTM 690 SMC R has a Power of 67.0 HP (48.9 kW).
How many gears does the KTM 690 SMC R have?
The 2018 KTM 690 SMC R has a Gearbox of 6-speed.
How much does the KTM 690 SMC R weigh?
The 2018 KTM 690 SMC R has a Dry weight of 141.0 kg (310.9 pounds).
